Lub ntsiab
API 5L (American Petroleum lub koom haum qhia tshwj xeeb 5L) yog tus qauv pom zoo rauKab YeebSiv rau hauv kev thauj mus los ntawm roj, dej, thiab roj hauv cov roj av thiab ntuj muaj kev lag luam.Pls1 (Theem Khoom Tshwj Xeeb Qib 1)yog ib qho ntawm peb cov khoom lag luam tshwj xeeb txhais tau nyob hauv API 5L, nrog PSL 1 sawv cev rautheem pib ntawm cov kev xav taurau cov kev siv hluav taws xob pipeline.
- PSL1: Qib qib no muab cov qauv ua haujlwm zoo rau kab rau kab. Nws teeb tsa qhov yooj yim uas yuav tsum tau rau cov khoom siv khoom thiab kuaj. PSL1 cov kav dej yog qhov tsim nyog rau cov ntawv thov xa xov dav dav.
Cov txheej txheem tsim khoom
- Ntaub ntawv: Cov ntaub ntawv raw siv rau kev tsim cov khoom API 5L PSL1 PIPES suav nrog kev siv, bille, billets, lossis daim hlau. Cov ntaub ntawv no feem ntau yog tsim los ntawm cov pa roj hmab, hluav taws xob rauv, lossis qhib hearth txheej txheem, ua ke nrog ladle refining.
- Hom Pipes: PSL1 cov kav dej tuaj yeem yog qhov tsis muaj dab tsi los yog welded. Seamless kav yog tsim los ntawm kub dov lossis extrusion cov txheej txheem, thaum welded kav hlau tuaj yeem siv cov qauv hluav taws xob xws li hluav taws xob vuam (pom).
Tshuaj Muaj Tshuaj
Cov tshuaj lom neeg muaj pes tsawg leeg ntawm API 5L PSL1 Pipes txawv nyob ntawm cov qib kawm tab sis feem ntau suav nrog cov ntsiab lus hauv qab no:
| Tshuaj lom neeg tshuaj lom neeg rau PSL 1 yeeb nkab nrog t tsawg dua lossis sib npaug rau 25.0 hli (0.984 hauv.) | ||||||||
|---|---|---|---|---|---|---|---|---|
| Qib hlau (Steel Npe) |
Pawg Feem Ntau Txheej Txheem, raws li cov khoom kub thiab khoom lag luam tshuaj xyuas A, G % |
|||||||
| C | Mn | P | S | V | Nb | Ti | ||
| Max B | Max B | lub min | tus zuag | tus zuag | tus zuag | tus zuag | tus zuag | |
| Seamless Yeeb Nkab | ||||||||
| L175 lossis A25 | 0.21 | 0.60 | - | 0.030 | 0.030 | - | - | - |
| L175p lossis A25P | 0.21 | 0.60 | 0.045 | 0.080 | 0.030 | - | - | - |
| L210 lossis a | 0.22 | 0.90 | - | 0.030 | 0.030 | - | - | - |
| L245 lossis b | 0.28 | 1.20 | - | 0.030 | 0.030 | c,d | c,d | d |
| L290 lossis X42 | 0.28 | 1.30 | - | 0.030 | 0.030 | d | d | d |
| L320 lossis X46 | 0.28 | 1.40 | - | 0.030 | 0.030 | d | d | d |
| L360 lossis X52 | 0.28 | 1.40 | - | 0.030 | 0.030 | d | d | d |
| L390 lossis X56 | 0.28 | 1.40 | - | 0.030 | 0.030 | d | d | d |
| L415 lossis X60 | 0.28 e | 1.40 e | - | 0.030 | 0.030 | f | f | f |
| L450 lossis x 65 | 0.28 e | 1.40 e | - | 0.030 | 0.030 | f | f | f |
| L485 lossis X70 | 0.28 e | 1.40 e | - | 0.030 | 0.030 | f | f | f |
| Welded Yeeb Nkab | ||||||||
| L175 lossis A25 | 0.21 | 0.60 | - | 0.030 | 0.030 | - | - | - |
| L175p lossis A25P | 0.21 | 0.60 | 0.045 | 0.080 | 0.030 | - | - | - |
| L210 lossis a | 0.22 | 0.90 | - | 0.030 | 0.030 | - | - | - |
| L245 lossis b | 0.26 | 1.20 | - | 0.030 | 0.030 | c,d | c,d | d |
| L290 lossis X42 | 0.26 | 1.30 | - | 0.030 | 0.030 | d | d | d |
| L320 lossis X46 | 0.26 | 1.40 | - | 0.030 | 0.030 | d | d | d |
| L360 lossis X52 | 0.26 | 1.40 | - | 0.030 | 0.030 | d | d | d |
| L390 lossis X56 | 0.26 | 1.40 | - | 0.030 | 0.030 | d | d | d |
| L415 lossis X60 | 0.26 e | 1.40 e | - | 0.030 | 0.030 | f | f | f |
| L450 lossis x 65 | 0.26 e | 1.45 e | - | 0.030 | 0.030 | f | f | f |
| L485 lossis X70 | 0.26 e | 1.65 e | - | 0.030 | 0.030 | f | f | f |
|
a. Cu tsawg dua lossis sib npaug rau 0.50%; Ni tsawg dua los yog sib npaug rau 0.50%; Cur tsawg dua lossis sib npaug rau 0.50% thiab mo tsawg dua lossis sib npaug rau 0.15%. b. Rau txhua tus kom txo ntawm 0.01% hauv qab qhov kev xav tau ntawm cov pa roj carbon ntau dua, nce siab ntawm 0.05% rau qib L245 lossis B, tab sis tsawg dua los yog X 560; Txog rau qhov siab tshaj plaws ntawm 1.75% rau qib> L360 lossis X52, tab sis lossis x70. c. Ntshe tsis tau pom zoo, nb + v tsawg dua lossis sib npaug rau 0.06%. d. NB + v + ti tsawg dua lossis sib npaug rau 0. 15%. e. Yog tsis pom zoo. f. Ntshe yog lwm tus pom zoo, nb + v + tsawg dua lossis sib npaug rau 0. 15%. g. Tsis txhob txhob txwm ntxiv ntawm B raug tso cai thiab cov seem ntawm qhov chaw lossis muaj sib npaug nrog 0.001%. |
||||||||
- PSL1 muajTsawg nruj npaum li txoj kev nrujPiv rau PSL2, uas tsis muaj kev txwv ntawm cov roj carbon sib npaug (CE) lossis microalloying ntsiab tshwj tsis yog hais tias muaj los ntawm tus neeg yuav khoom.
Cov Khoom Siv Neeg Kho Tshuab
| Yuav tsum muaj rau cov kev ntsuam xyuas Tensile rau PSL 1 yeeb nkab | ||||
|---|---|---|---|---|
| Yeeb Nkab Qib | Yeeb Nkab Lub Cev Ntawm Seamless Thiab Welded Yeeb Nkab | Weld Seam ntawm EW, LW, pom, thiab nyuj Tus kav dej |
||
|
Paib zog a RT0.5 |
Tensile lub zog a Rm |
Elongation (ntawm 50 hli lossis 2 hauv.) Tus fab % |
Lub zog tensile Rm |
|
| lub min | lub min | lub min | lub min | |
| L175 lossis A25 | 175 (25,400) | 310 (45,000) | c | 310 (45,000) |
| L175p lossis A25P | 175 (25,400) | 310 (45,000) | c | 310 (45,000) |
| L210 lossis a | 210 (30,500) | 335 (48,600) | c | 335 (48,600) |
| L245 lossis b | 245 (35,500) | 415 (60,200) | c | 415 (60,200) |
| L290 lossis X42 | 290 (42,100) | 415 (60,200) | c | 415 (60,200) |
| L320 lossis X46 | 320 (46,400) | 435 (63,100) | c | 435 (63,100) |
| L360 lossis X52 | 360 (52,200) | 460 (66,700) | c | 460 (66,700) |
| L390 lossis X56 | 390 (56,600) | 490 (71,100) | c | 490 (71,100) |
| L415 lossis X60 | 415 (60,200) | 520 (75,400) | c | 520 (75,400) |
| L450 lossis x 65 | 450 (65,300) | 535 (77,600) | c | 535 (77,600) |
| L485 lossis X70 | 485 (70,300) | 570 (82,700) | c | 570 (82,700) |
|
Ib qib nrab, qhov sib txawv ntawm qhov tsawg kawg tensile lub zog thiab tau teev tseg yam tsawg kawg zog zog lub zog rau lub cev nqaij yeeb yuav muab rau hauv cov lus rau qib tom ntej. B rau qib nrab qib kawm, lub zog tsawg tshaj plaws rau kev txiav txim siab Weld yuav txiav txim siab tib tus nqi uas siv cov raj xyoob siv cov lus taw qhia a). C Qhov kev teev tseg tsawg kawg, AF, qhia nyob rau feem pua thiab sib npaug rau feem pua ze tshaj plaws, yuav tsum yog txiav txim siab siv kab sib npaug hauv qab no:
qhov twg C yog 1940 rau kev xam siv cov kev siv SI thiab 625,000 rau kev suav siv USC units AXC yog qhov muaj feem xyuam Tensile sib txuas lus daim Cross- seem ntawm thaj chaw, qhia nyob rau hauv thaj av square (square millimeters (square ntiv tes), raws li hauv qab no: |
||||
|
1) Rau cov ntoo khaub lig ncig - mm2 (0.3 mm2) rau 12.7 hli (0.500 hauv.) Cawv (0.350. 65 mm2 (0. 10 in.2) rau 6.4 hli (0.250. 2) rau tag nrho {-}} ntu ntawm ib qho) 485 mm2 (0.75 mm2 (0.75 3) Rau cov kab ntawv xeem sawb daim, tus neeg qis dua ntawm) 485 mm2 (0.75} Tus ntoo khaub lig Thickness ntawm cov yeeb nkab ntawm cov yeeb nkab, sib npaug mus rau qhov ze tshaj 10 mm2 (0.01 in.2); U yog qhov kev txiav txim siab tsawg tensile lub zog, qhia nyob rau hauv megapascals (phaus ib square nti). |
||||
- Tensile zog, tawm los lub zog, thiab elongation yog sim tab sis nrogtsawg dua kev txwvtshaj PSL2.
- Charpy cuam tshuam kev xeem tsis yog yuav tsum tau uaTshwj tsis yog hais tias teev rau tsawg -} sov daim ntawv thov.
Kev Soj Ntsuam & Tshuaj Xyuas
Hydrostatic Kuaj: Yuav tsum ua rau txhua PSL1 kav.
Tsis - kev sim tshuaj ntsuam (ndt):
- Welded Kav: Rau welded kav nrog lub taub sab nraud ntau dua lossis sib npaug rau 2.375 nti (60 hli), 100% ndt yuav tsum muaj. Cov hau kev suav nrog sib nqus particetle particle partlefection, kua tshuaj ntsuam xyuas, ntsuas hluav taws xob, thiab kuaj ultrasonic.
- Seamless Pipes: NDT cov cai yuav txawv raws li cov txheej txheem kev tsim qauv thiab kev tsim khoom.
Xaus ua tiav thiab cov kev kho mob saum npoo
Kawg ua tiav
API 5L PSL1 Cov kav dej tuaj yeem muaj qhov kawg xaus lossis beveled xaus, nyob ntawm daim ntawv thov yuav tsum tau ua.
Tsho thiab cov kev kho cov nplaim
- Nplaim: Options include bare, black, lightly oiled, hot-dip galvanized, varnish coating/anti-rust oil, or protective coatings.
- Txheej: Rau kev tiv thaiv corrosion, kav dej yuav muab coated nrog cov ntaub ntawv xws li peb {{}} txheej polyethylene (3pe).
Cov ntawv thov thiab cov txiaj ntsig
Cov Ntawv Thov
- Tsawg - -} nruab nyiaj nruab nrab & roj pipelines
- Dej Sib Kis
- Cov qauv thiab dav dav - lub hom phiaj piping(qhov twg cov tawv tawv tsis yog qhov tseem ceeb)
Qhov Zoo
- Tus nqi qisVim yog yooj yim ntau lawm thiab kev xeem.
- Haum rau tsis -} tseem ceeb ib puag ncigqhov twg siab tawv tsis tsim nyog.
Lub ntsiab
API 5L PSL1 cov kav dej tau siv dav hauv cov roj thiab roj kev lag luam rau lawv txoj kev ntseeg tau thiab cov qauv zoo. Lawv muaj nyob rau ntau qhov ntau thiab tsawg ntau thiab tsawg qeb, thiab xa khoom kom tau raws li cov raj xa hluav taws xob sib txawv. Cov txheej txheem tsim khoom, tshuaj lom neeg, thiab cov khoom siv neeg kho mob yog nruj nruj tswj hwm kom ntseeg tau kev ua tiav thiab kev nyab xeeb hauv kev pabcuam.
